Latitude is for sale! 52,000
All good things must come to an end.
Due to some unexpected changes in our life, we realize it’s time to let her go.
We have enjoyed sharing her with so many sailing on the San Francisco Bay!
Now it’s time to turn her over to someone new!
Feel free to call for more information. 408 406-3884
The hull is 4 layers of 3/8” mahogany planking with two layers of fiberglass matting. All done with West System.
The deck is 2x3 virtical grain douglas fir over 3/8' marine plywood.
The cabins and trunk cabins are 4x8 douglas fir through bolted with 5/8" stainless rod.
In the last few years, we completely rebuilt the 471 Detroit Diesel, installed a new furuno color LCD fish finder, new electric toilet, new EPIRB, new bilge pumps and a new six man Revere coastal survival raft and much more!
She was hauled out in March of 2023 for hull and bottom paint, zinks and a new propeller.
Additional information:
Hull: Hartog Schooner
Built by PAUL ZUPAN/GEORGE ALLEN
San Francisco, CA
Year: 1976-1999
LOA: 60’ 0”Beam:15’ 6”
Draft: 6’ 4”
Freeboard Aft: 36”
Hull Framing:
OAK AND FIR FRAMING
Hull planking:
COLD MOLDED HONDURAS MAHOGANY
Fasteners: Condition:
BRONZE RING SHANK NAIL GOOD
Keel: Battens: Chine:
LEAD BALLAST N/A N/A
Deck Beams: Deck: Cabin construction:
FIR AND OAK FIR TIMBER DECKING PLYWOOD OVER OAK/FIR FRAMES
Bulkheads: Escape hatches:
MARINE PLY CENTER BUTTERFLY HATCH
General Construction:
COLD MOLDED WOODEN AFT COCKPIT SCHOONER WITH INBOARD DETROIT DIESEL ENGINE
ENGINE AND MACHINERY
DETROIT DIESEL 471
DETROIT INBOARD 1.5 :1 TWIN DISC
Year Built/Installed:1990 Last Overhaul:
2017
Eng Hours Port:
300
Drip Pan: Fuel Bowls: Fuel Filters:
RACOR CANISTER
Location of Fuel Tanks: Grounded:
(4) PORT & STARBOARD SIDE OF ENGINE ROOM 150 GAL EACH YES
Tank Material: Fill Location: Vented:
STEEL COATED
Fuel Lines: Shut Off Valves:
COPPER AND FITTED ALL GOOD CONDITION YES
SEA CONNECTIONS
Main Engine Cooling: Sea Valve: Piping Material:
Condition:
RAW WATER/HEAT EXCHANGER (1)NEWER BRONZE MARINE HOSE , GOOD
NEW Electric ToiletToilet Inlet Location: Sea Valve:
PORT UNDER CABINET BRONZE
Intake Material: Discharge: Condition:
SEAWATER TANK/DECK FITTING GOOD
Treatment/Holding Tank:
YES / 20GAL & 150 GAL
MECHANICAL
Propeller Shaft: Material: Bearing:
1-3/4" STAINLESS BRONZE/RUBBER COMP.
Condition of shaft, bearings, strut & rudder: GOOD
Propeller: Protected:
BRONZE 24 RH 22 3-BLADE BRONZE ZINC ANODES (RUDDER AND SHAFT)
N/A NATURAL/BLOWERS
Exhaust System: Muffled:
STAINLESS YES
Bilge Pumps:
(2) 12VDC 2000 gph CENTRIFUGAL WITH AUTO FLOATS
ELECTRICAL
Shore Side: Fused: Polarity Indicator:
120VAC 50A YES YES
Underway:
(1) 12VDC 100 AMP ALTERNATOR
Batteries: Secured: Master Switch: Parallel:
(1) 4D 12VDC (2) 6V HOUSE YES YES YES 12V / SERIES 6V
Nav. lights: TRI COLOR TOP MAST UNDER SAIL, CABIN TOP PORT AND STARBOARD LTS.
Type of Wiring:
120VAC/12VDC ALL MARINE GRADE
Stove: FORCE 10 (3) BURNER PROPANE AFT
Refrigeration:
FRIGOBOAT 12VDC
Fresh Water Tank: Capacity:150GAL
Hot Water Heater:20GAL
Sinks:
FORWARD HEAD AND GALLEY
FIRE FIGHTING EQUIPMENT
Built in Automatic system:
MOUNTED SECURE IN ENGINE ROOM
Fire Extinguishers:
No. & Size Type: Loc: Inspected:
1-3LB B/C HEAD 2017
1-3LB B/C GALLEY 2015
1-3LB A/B/C AUTO GALLEY 2014
5 LB A/B/C AUTO ENGINE ROOM 2016
DECK EQUIPMENT
Life Jackets: Location:
6 TYPE 2PFD LAZARETTE/AFT CABIN
Liferaft: 6 PERSON
Anchor:YES (2)GALVANIZED CQR 300’ 5⁄8” CHAIN
Deck Machinery:
WINDLASS 12VDC
SPECIAL EQUIPMENT
NEW Furno color fish finderAutopilot: Compass: Radar:
RAYMARINE RITCHIE
EPIRB: FLIR/Broadband Radar:
YES, GLOBALFIX V4 NO NO
VHF: SAT/NAV/GPS: Depth Sounder:
STANDARD HORIZON RAYTHEON YES
Bell: YES Horn: YES Fenders:YES Flares: YES Wiper:
First Aid: Bilge Control Plaque: Boarding Ladder:
Bow Rail: Stern Rail: Lifelines/Handrails:
STAINLESS STAINLESS STAINLESS CABLE
Awnings/Canvas: Battery Charger:
100A HEART W/ INTERFACE
COMMENTS, SAILS, ACCESSORIES AND OTHER:
SAIL IN FAIR CONDITION, HEAD SAIL IS ON A ROLLER FURLER
SMOKE DETECTOR INSTALLED AND OPERATIONAL IN CABIN
RAYMARINE ELECTRONICS THROUGHOUT INCLUDING WEBASTO DIESEL CABIN HEATER.
